PDS Series SMD Power Inductor
| Size | Dimensions | L (mm) |
W (mm) |
H (mm) |
Mount | |
|---|---|---|---|---|---|---|
| PDS3215 | 3.2 | 2.5 | 1.75 | SMD | ||
| PDS3222 | 3.2 | 2.5 | 2.3 | SMD | ||
| PDS4530 | 4.5 | 3.2 | 3.0 | SMD | ||
| PDS5750 | 5.7 | 5.0 | 5.1 | SMD |
Characteristics:
Miniature chip inductor wound on a special ferrite core
Small inductances for compact circuits
High Q at high frequencies
Low DC-resistance
Operating temperature: –40 ºC to +125 ºC
Recommended solder profile: Reflow
Applications:
Low power DC/DC-converters from Linear Technology, National Semiconductor, Texas Instruments, Fairchild Semiconductor, ON Semiconductor, STMicroelectronics, Maxim, MPS, Semtech, Exar, Analogic Tech, Diodes and Cologne Chip
EMI-Filtering
RF-circuits
